The minimum size for a cabinet box component with edgebanding is 3" x 3" [76.2mm x 76.2mm].
• Sizes below minimum may be available, but additional charges will apply.
• Please submit your requests to our Customer Support Team.
Cabinet Box Component Options
Toe Kick Rabbet
Depth, Width and Height Required
Bottom Dado Groove Placement Required
Distance from Center of Shelf Hole to Edge of Panel
Top Dado Groove Placement Required
Complex Components
Distance from Center of Shelf Hole to Center of Shelf Hole
Back Dado Groove Placement Required
Base Side - Left
Back Dado Groove Placement Required
Distance Between Centers of Shelf Bore Holes
Toe Kick Notch Depth and Height Required
Bottom Dado Groove Placement Required
Top Dado Groove Placement Required
Distance from Center of Shelf Hole to Center of Shelf Hole Face
Back Dado Groove Placement Required
Bottom Dado Groove Placement Required Start
Base Side - Right
Back Dado Groove Placement Required
Distance from Center of Shelf Hole to Edge of Panel
Distance Between Centers of Shelf Bore Holes
Bottom Dado Groove Placement Required
Toe Kick Notch Depth and Height Required
Toe Kick Rabbet
Depth, Width and Height Required
Complex Components
Dado Width Disclaimer
Cabinet Box Component Options
• When choosing to apply a dado to a cabinet component, you must always be aware of the finished thickness of the part that's being inserted into the dado.
• All material thicknesses come with a +/- tolerance, meaning the thickness could fluctuate as much as 0.5mm.
• Adding finish to your part will also increase the overall thickness.
• The width of your dado should always be slightly wider than the finished material thickness.
• WalzCraft recommends setting your dado width after measuring your part's finished thickness.
Please use Sheet Goods Order Forms (E•Z Forms #8, #8.1, #8.2)
Use part #1631 for complex cabinet box components.
1Order Forms
2Drawings Required
1Pricing
1 Customized Cabinet Box Components
2Toe Kick Notch
3Edgebanding
Email your drawings and order forms to our Customer Support Team at customersupport@WalzCraft.com, or you can fax them to 1-608-781-3667.
Order Forms / Drawings should include the following information for the machining operations noted here, as well as any additional customization needed (see examples on previous page):
• Component materials.
• Overall width and height, as well as thickness of the component.
• All dado groove widths and depths and the placement of each dado groove from edge of panel.
• Shelf bore hole information:
◦ Position of holes from the edge of the end panel.
◦ Depth and diameter of holes.
◦ Start and stop points of holes from the top of the panel to the center of the holes.
• Depth, width and height for toe kick rabbet.
• Depth and height for toe kick notch.
• Edgeband location should be noted as follows: Top (T), Bottom (B), Left (L) or Right (R), viewing panel from face.
Pricing
Please see Section L.2 of our current Wholesale Pricing Catalog
Complex (Customized) components will consist of cabinet parts that require additional machining operations
• Operations may include dadoes, shelf bore holes, toe kick notches, etc.
• These components may be used as cabinet sides, backs, tops, floors, partitions, shelves, etc.
When ordering cabinet end panels with a toe kick notch, WalzCraft refers to the notch from the point of view of an assembled cabinet with a toe kick recess. For WalzCraft to correctly cut the notch to your specifications, please indicate depth x height.
Complex components in plywood, custom pressed material and melamine are available with edgeband treatment option EBT201.
• Edgebanding is machine applied to core material with sheeting on the face and back.
Complex components in raw MDF are available with edgeband treatment option EBT102
• Maple veneer edgebanding is machine applied to a raw MDF panel, no veneer on face or back.
EBT201
EBT102
When applying edgeband material to a custom pressed panel or a cabinet box component, the finished thickness of the panel must be 3/4" thick or less.
• When custom pressing, we recommend using 11/16" core material to achieve a nominal 3/4" finished thickness.
